IFT iFusion - Advanced Inverter Manufacturing

Why Choose IFT iFusion

Leading inverter manufacturing with cutting-edge technology and global expertise

Advanced Quality Management

Our products undergo rigorous testing and quality control to ensure reliability and performance.

Engineering Excellence

Precision engineering and rigorous quality control for superior inverter performance

Quality Assurance

Comprehensive testing and certification for reliable inverter performance worldwide

Advanced Manufacturing

State-of-the-art inverter manufacturing with industry-leading precision

What Our Clients Say

Trusted by businesses and homeowners across Pakistan

"The PV5000-24 3.6kW inverter has been perfect for our residential solar setup. The efficiency and reliability are outstanding, and the after-sales support is excellent."

Muhammad Imran

Residential Solar Installer, Lahore

"We installed multiple PV9000-48 6kW inverters in our commercial project. The performance and efficiency are remarkable, and the monitoring features are very useful for our operations."

Ayesha Malik

Commercial Solar Developer, Islamabad

"The combination of PV5000-24 and PV9000-48 inverters in our mixed-use development has been fantastic. The consistent performance and IFT iFusion's technical support are unmatched."

Zain Ahmed

Project Manager, Karachi

Frequently Asked Questions

Get answers to common questions about our products and services

View Complete FAQs

IS YOUR PCB BOARD SIMILAR TO VOLTRONICS?

The vast majority of product functions and performance at the same level compare with Voltronic, but there have differences in software and hardware design for the PCB board. Our PCB layout is more compact, and our PCB board has a smaller size at the same rated output power.

The highlights of our PCB design and process are as follows:

Dual-Layer PCB & Compliant With the World's Toughest Grid Codes
- Dual-layer PCBA isolates control and power circuits for superior EMI immunity and heat dissipation.
- Meets IEEE, EN, CEC G99 standards—true plug-and-play worldwide.
Premium Components & Direct Tier-I Sourcing
- Core parts sourced directly from Infineon, Texas Instruments, Murata, Panasonic and other top brands.
- Qualified to AEC-QlOO/200 & UL94V-O standards, achieving defect rates well below the industry average.
DJI & Huawei-Grade Manufacturing & Best-in-Class QA
- SMT, AOI/SPI, final assembly and 48h full-load burn-in are performed in DJI/Huawei-certified smart factories.
- End-to-end MES traceability guarantees rock-solid reliability from day one.

WHAT KIND OF PROTECTION HAS DC, AC AND BATTERY?

AC mains input: Abnormal high/low voltage protection for Grid power supply (90-280VAC, minimum starting voltage 90V)

DC battery input: Battery high/low voltage protection (LFP battery 40V -61V)

DC PV input: PV high/low voltage protection

AC output:

Overload protection (3.6KW inverter can support 150% overload max at 200ms, 6kw can support 120% overload max in 10S)
Short Circuit Protection
Output overvoltage and undervoltage protection

Once there is reverse polarity operation, the possible consequences are as follows:

Protection Comparison:

Battery Reverse: Yes (Active)
Fuse: No (Not required)
Norms operation: T destruction, PCB <500ms

DOES THE INVERTER WORKS WITHOUT GRID WITHOUT BATTERY? ONLY PV INPUT

Yes, both 3.6KW and 6KW inverter support work without Grid and without battery under PV input only.

WHAT CAPACITY IT WORKS WITHOUT GRID WITHOUT BATTERY? ONLY PV INPUT

If the PV energy is sufficient with good sunshine, it can reach the rated output power.

WHAT KIND OF BATTERY COMMUNICATION PROTOCOLS ARE USED AND DOES IT WORKS WITH ALL KIND OF LITHIUM IRON BATTERIES?

3.6KW inverter: Supports low voltage (24V/25.6V) BMS protocol including PYLON 485/CAN;

6KW inverter: Supports low voltage (48V/51.2V) BMS protocol including PYLON 485/CAN;

Only the LFP battery pack supports the above mentioned BMS protocol and can communicate with the inverter. The Inverter can support Lead acid battery including AGM and flooded type but no BMS communication.
